| DG 202 | Scale M 1:3,5 Model with wings and elevator ready to cover | ||||||||||||||||
| DG 202 / 15 | Wingspan 4,29 m | Ref. N°. | rk450 15 | 689,00 | |||||||||||||
| DG 202 / 17 | Wingspan 4,86 m | Ref. N°. | rk450 17 | 699,00 | |||||||||||||
| DG 202 / 17 with flaps | Wingspan 4,86 m | Ref. N°. | rk450 17w | 749,00 | |||||||||||||
| Prices including V.A.T. | |||||||||||||||||
| These models are used on slopes and flatlands. Winch-launch and F-towing are problem-free. The speed range is extremely wide. With the 4.29 m version the aerobatics and high speed flight characteristics predominate, the models with 4.86 m wingspan are more optimized for high performance thermal flights, whereby the ranges overlap. | |||||||||||||||||
| Content of delivery and description of the finished parts: | |||||||||||||||||
| High-gloss GRP fuselage, white, reinforced several times, smooth-running Bowden cable for rudder built in. Cable for elevator servo installed in fuselage. The positions for wing plugging and landing gear shaft flaps are clearly marked. The fin end strip made of GRP is completely installed. | |||||||||||||||||
| Canopy in clear colorless or smoked colour on request. | |||||||||||||||||
| Ready to cover abachi planked wings with sufficient glass inlays, double-decker 37cm TECK spoilers installed, ailerons (and flaps if necessary) cut out and cast. Reinforcements at the servo cut-outs worked in, wing plug completely worked in, twisted servo cables inserted. | |||||||||||||||||
| One-piece balsa-planked horizontal tailplane to screw on, ready for covering. | |||||||||||||||||
| White rudder in GRP shell construction, swivel bearing ready fitted. Only the rudder horn has to be mounted. | |||||||||||||||||
| Fibreglass fin end strip with feed-through for the rudder linkage. (Already mounted in the fin end.) |
|||||||||||||||||
| Set of small parts with the following contents: Wing clamp- spar bridge, brass tube for torsion steels, prefabricated GFK servo plate for the admission of the HLW servo in the fin, rudder bearing, rudder horns for aileron and rudder, cab lock, detailed illustrated building instruction. | |||||||||||||||||
| Technical data: | DG 202 / 15 | DG 202 / 17 | DG 202 / 17 Wφlb | ||||||||||||||
| Wingspan | 4290 mm | 4860 mm | 4860 mm | ||||||||||||||
| Length over all | 2000 mm | 2000 mm | 2000 mm | ||||||||||||||
| Height over all | 490 mm | 490 mm | 490 mm | ||||||||||||||
| Wing profile on the fuselage | keine | keine | keine | ||||||||||||||
| Wing width at the fuselage | 260 mm | 260 mm | 260 mm | ||||||||||||||
| Fuselage width at wing connection | 150 mm | 150 mm | 150 mm | ||||||||||||||
| Wing area | 82,65 dm2 | 91,25 dm2 | 91,25 dm2 | ||||||||||||||
| Wing profiles | E 203 / E 201 / E 197 | E 203 / E 201 / E 197 | E 203 / E 201 / E 197 | ||||||||||||||
| Elevator- span | 720 mm | 720 mm | 720 mm | ||||||||||||||
| Elevator area | 9,36 dm2 | 9,36 dm2 | 9,36 dm2 | ||||||||||||||
| Stabilizer profile | NACA 0009 | NACA 0009 | NACA 0009 | ||||||||||||||
| Weight RTF approx. | 6300 gr | 6500 gr | 6600 gr | ||||||||||||||
| G -load max. (Resilience) | 13 G | 11,5 G | 11,5 G | ||||||||||||||
| Optional accessories : ( to order additional ) | Ref. N°. | Price with VAT | |||||||||||||||
| GRP canpy frame ( very stable) | rk45012 | 30,90 | |||||||||||||||
| Cockpit- Sitzwanne, tiefgezogen und Instrumentenpilzhalter aus GfK | rk450121 | n.m.lieferbar | |||||||||||||||
| Instrumentenpilz aus GfK | rk450122 | n.m.lieferbar | |||||||||||||||
| 1 Slide window 1 : 3,5, compl. with Guide rails and 6 screws M1 | rk1003.3,5 | 9,50 | |||||||||||||||
| Scale seatbelt 1:4 with illustration | rk1010 | 9,95 | |||||||||||||||
| Set of joystick, spoiler actuating lever and microphone, scale 1:4 | rk1011 | 9,95 | |||||||||||||||
| Set of instruments 1:3 | rk1013 | 12,95 | |||||||||||||||
| Retractable landing gear for wheels 100 mm Ψ | ho100 | 81,00 | |||||||||||||||
| Retractable landing gear with brake for wheels 100 mm Ψ | ho100br | 103,00 | |||||||||||||||
| High-load-quality-wheel 100 mm Ψ, with Nylon-rim | mx733094 | 9,90 | |||||||||||||||
| Very high-load-quality-wheel from foam rummer, 100 mm Ψ, with Nylon-rim | ct5599Fe | 18,50 | |||||||||||||||
| Tailwheel 50 mm Ψ | gr165.50 | 3,20 | |||||||||||||||
| GRP wheel cover for tail wheel 60 mm Ψ | rk1018 | 6,20 | |||||||||||||||
| Tow release for installation in fuselages front end | kd1186 | 13,95 | |||||||||||||||
| Tow hook for winch launch (2 pc.) | gr627 | 3,00 | |||||||||||||||
| Pair stickers DG 202 | rk450891 | 5,20 | |||||||||||||||
| Pair of D-flags, small, 60x35 mm, for sticking to the side fin | rk1220 | 2,30 | |||||||||||||||
| 1 pair of wings protecting bags from 3 - layer bubble wrap | rk45091 | 34,50 | |||||||||||||||
| Protection bag for stabilizer, made from 3 - layer bubble wrap | rk45092 | 9,50 | |||||||||||||||
| Spare parts | |||||||||||||||||
| Item title | Ref. N°. | Price | Item title | Ref. N°. | Price with VAT | ||||||||||||
| Fiberglass fuselage, white, with built-in-ring-ribs, bowden cable, cable for elevator-servo and side fins conclusion | rk4501 | 172,00 | Pair finished wings with ailerons and airbrakes, 4,86 m wingspan | rk4503 1 | 396,00 | ||||||||||||
| Side fins conclusion | rk4501a | 8,65 | Pair finished wings with ailerons, airbrakes and flaps, 4,86 m wingspan, with flaps | rk4503 w | 446,00 | ||||||||||||
| Canopy glass, transparent colorless | rk4502f | 21,95 | Stabilizer styrofoam/balsa, ready to cover | rk4504 | 48,50 | ||||||||||||
| Canopy glass, transparent smoke-colored | rk4502r | 21,95 | GRP rudder, white | rk4505gfk | 51,00 | ||||||||||||
| Pair finished wings with ailerons and airbrakes, 4,29 m wingspan | rk4503 0 | 389,00 | Wing steel insertion device for fuselage | rk4506 | 28,60 | ||||||||||||
| Services to the model | |||||||||||||||||
| Operation | Ref. N°. | Price with VAT | |||||||||||||||
| Shaping of the curved fuselage contour to the root-ribs of the wings (this is done with a GRP mould) | rk450s099 | 31,80 | |||||||||||||||
| Installation and adjustment of the wing-joiner bracket in the fuselage | rk450s1 | 69,70 | |||||||||||||||
| Installation of the aluminium fuselage shoring 1060 in the fuselage between leading edges | rk450s13ra | 14,50 | |||||||||||||||
| Absolute gap-free fine adjustment of the wing contour to the fuselage | rk450s11 | 16,90 | |||||||||||||||
| Assembly of the cabin frame and cabin lock on the fuselage | rk450s14 | 38,00 | |||||||||||||||
| Installation of stabilizer, rudder, the associated linkage and the side fin conclusion. | rk450s151 | 91,00 | |||||||||||||||
| Cutting out the doors for the landing gear and fasten with silicone hinge | rk450s7 kl | 54,00 | |||||||||||||||
| Installation of the retractable gear and door-closure-device (without servo mount) | rk450s7 xf | 126,00 | |||||||||||||||
| Adjusting and gluing the canopy to the canopy frame | rk450s832 | 96,00 | |||||||||||||||
| Further service works, which can lead up to the ready to fly model, on detailed inquiry! | |||||||||||||||||
| roke - modelle, Roland Kern Rosenstrasse 2, D - 72827 Wannweil, Tel.: 0049 7121 - 57 336, FAX: 0049 7121 - 54 439 | E-mail to ROKEMODELL | ||||||||||||||||
| More informations about this and other ROKE- models you can see in our Video ROKE - Modelle. We present the models in as-delivered condition and in the flight. The video has a running time of over 2 hours and is accompanied from wonderful music in HiFi hiFi-Stereo. | |||||||||||||||||
| The video is on stock: | Order- No. | rk10 | Price | ||||||||||||||
